AT2-5BS4E-G Universal Defrost Controller with two sensors

Main features:
Selectable Refrigerating or Heating control
Runs on mains power supply
Direct compressor control through high power 16(5)A
Excellent evaporator fan control
Auxiliary output configurable in six different operating modes
Selectable NTC10K or PTC input
Electrical, off cycle or hot gas defrost
Absolute or relative tempera_ture alarms
Door open alarm
Automatic condenser maintenance war_ning
On/Off button _ Optional light control button _ Quick programming through ZOT-AT2 key

Applications: High or Low Temperature upright cabinets and counters, cold stores, plug-in display cases, control panels, heated cabinets.

Technical Data:
Control Range: -50?120?C , -55?240?F
Resolution: 0.1 / 1 ?C; ?F
Accuracy:
– NTC10K: <?0.3?C (-40.0?70.0?C)
– PTC1000: <?0.5?C (-50?120?C)
Sensor type: selectable NTC10K or PTC1000
Power supply: 230V~ ?10% 50?60Hz 3W
Front protection: IP55
Panel cut-out: 71×29 mm
